| MODEL |
R3 |
| SURFACE FINISHING |
In-mould labelling (IML), poly carbonate (PC) & acrylonitrile butadine systene (ABS) |
| TYPE OF SCANNER |
Non coated optical scanner |
| PROCESSOR |
400 MHz |
| MEMORY |
256 MB flash memory & 32MB SDRAM |
| ALGORITHM |
Biobridge VX 10.0 |
| PUSH TECHNOLOGY |
Yes |
| PRODUCT DIMENSION (L X W X H), mm |
78 x 32 x 190 |
| STORAGE |
| • Fingerprint templates |
3,000 |
| • Card |
10,000 |
| • Transaction logs |
100,000 |
| ENROLLMENT & VERIFICATION |
| • Methods |
Fingerprint (1:1, 1:N), card & password |
| • Recommended fingerprint per user ID |
2 |
| • Fingerprint placement |
Any angle |
| • Verification time (sec) |
< 1 |
| • FAR (%) |
< 0.001 |
| • FRR (%) |
< 1 |
| CARD TECHNOLOGY |
| • RFID: 64-bit, 125kHz |
Yes |
| • MIFARE: MFIS50/S70, 13.56MHz |
Made to order |
| COMMUNICATIONS |
| • Method |
TCP/IP, RS232, RS485, USB disk |
| • Baud rates |
9600, 19200, 38400, 57600, 115200 |
| • Wiegand |
26-bit input / output |
| OPERATING ENVIRONMENT |
| • Temperature (°C) |
0 ~ 45 |
| • Humidity (%) |
20 ~ 80 |
| • Power input |
DC 12V 3A |
| TIME ATTENDANCE |
| • Work codes |
Yes |
| MULTIMEDIA |
| • Greeting voice |
Yes |
| • Display |
2.4” 3k color LCD |
| • Photo-ID |
Yes |
| • Short messaging |
Yes |
| ACCESS CONTROL |
| • EM lock driving output |
DC12V 3A / relay output |
| • Alarm output |
NO/NC |
| • Antipassback |
Yes |
| VOICE / DISPLAY LANGUAGE (TERMINAL) |
English (Standard), Arabic, Chinese (Simplified/Traditional), Indonesian,
Portuguese (Portugal), Spanish.
Other languages are available upon request. |
