QR110 | FingerTec

QR110

QR110 | FingerTec

QR 110
Distinctive Combination of QR Code & Card

2 YEARS LIMITED WARRANTY

Reading Speed and Interval
Performance at Its Finest

Speed
< 0.2 sec

Interval
< 0.5 sec

Verification & Communication
Different Credetials to Cater Unique Needs

Verification

QR Code
Card


QR Code	Card

Communication

	Wiegand
	RS485


Wiegand	RS485

Several Card Compatibility
Leverage One That Serve the Purpose

RFID • MiFare

Visitor Pass
Multi-Function Reader

Create a time-sensitive QR code that sets temporary access for visitors.

Low Implementation Cost
Simple Yet Effective

By utilizing a smartphone, users can carry the QR code to gain access without having to invest in additional tokens or gadgets.

Layout Plan

Installation Diagram
for illustration only

* R2 and R2c can be installed indoor or outdoor based on your preference. It is recommended to install R2 indoor to avoid vandalism

Specification

MODEL	TA100C
DIMENSION (L X W X H), mm	86 x 40 x 86
CREDENTIALS	QR Code RFID EM Card 125KHz MiFare Card 13.56MHz (Made to order)
OUTPUT FORMAT	Wiegand 26/34
COMMUNICATION DISTANCE	Wiegand < 100m RS485 < 1200m
WORKING VOLTAGE	DC 9 ~ 16V
WORKING CURRENT	< 100mA
WORKING ENVIRONMENT	Temperature (°C): -10 ~ 70 Humidity (%): 10 ~ 70 (Indoor use)
SENSING DISTANCE	QR Code (cm): 3~10 Cards (cm): 2~3
READING SPEED	< 0.2 seconds
READING INTERVAL	<0.5 seconds
SUPPORT	Q2i, R3, R2, Face ID 3, Kadex, m-Kadex, Ingressus I/II/IV
