| MODEL |
Ingressus I |
Ingressus II |
Ingressus IV |
| BASIC |
|
|
Dimension
(L X W X H), mm |
186 x 106 x 36 |
226 x 106 x 36 |
| Power input |
12V DC |
| Operating temperature (°C) |
0 - 55 |
| Operating humidity (%) |
10 - 80 |
| CPU |
32-bit, 400MHz |
| Flash memory (MB) |
128 |
| SDRAM (MB) |
32 |
| Polarity protection |
Yes |
| STORAGE |
|
| Fingerprints |
3,000 |
| Cards |
30,000 |
| Passwords |
30,000 |
| Transactions |
100,000 |
| COMMUNICATIONS |
|
|
|
| Communications with server |
TCP/IP |
| Quantity of terminal |
2 |
4 |
4 |
| Communication with terminals |
2 x 26-bit Wiegand input. Each for 1 slave terminal (1 x RS485 input to support RS485 network)
(max 2 units) |
4 x 26-bit Wiegand input. Each for 1 slave terminal (1 x RS485 input to support RS 485 network)
(max 4) |
4 x 26-bit Wiegand input. Each for 1 slave terminal (1 x RS485 input to support RS 485 network)
(max 8 units) |
| INPUT |
|
|
|
| Push release button |
1 |
2 |
4 |
| Door sensor |
1 |
2 |
4 |
| AUX |
1 |
2 |
4 |
| Types of AUX input supported |
Motion detector, passive DIR detector, curtain passive infrared detector, pet immunity PIR detector, two beam digital active infrared detector, heat detector |
| OUTPUT |
|
|
|
| Door lock (12VDC 10A form C relay) |
1 |
2 |
4 |
| AUX output (30VDC 2A form C relay) |
1 |
2 |
4 |
| Types of AUX output supported |
Gas detector and compatible sensors, Piezo strobe siren, electronic siren |
| ACCESS CONTROL FEATURES |
|
|
|
| Main Features |
Door opening time (0-999s), Inter-locking (lnggressus II & IV only), Anti-pass back (Local only), Multi card unlocking, First card unlocking, Time zone (50), Holiday time zone, Permanent door release/ lock time zone, Day light saving time zone, Continuous verification of users |
| Security Features |
Door force open alarm, Door open time out alarm, Fire linkage, Duress alarm, Door status and event (51 types) |
