MODEL |
Face ID 2 |
SURFACE FINISHING |
Acrylonitrile Butadiene Styrene (ABS) & Acrylic |
TYPE OF SCANNER |
Hi-res infrared camera & fingerprint scanner |
PROCESSOR |
1.2GHz |
MEMORY |
128MB Nand flash & 64MB Nand flash |
ALGORITHM |
Face BioBridge VX8.0, Fingerprint BioBridge VX9.0 / 10.0 |
PRODUCT DIMENSION (L X W X H), mm |
194 x 110 x 145 |
STORAGE |
• Fingerprint templates |
10000 |
• Face templates |
1200 |
• Card |
10000 |
• Transaction logs |
200000 |
ENROLLMENT & VERIFICATION |
• Methods |
Face (1:1, 1:N), fingerprint (1:1, 1:N), card & password |
• Recommended fingerprint per user ID |
2 |
• Fingerprint placement |
Any angle |
• Verification time – Face, sec |
<2 |
• Verification time – Fingerprint, sec |
< 1 |
• Fingerprint |
FAR < 0.0001%, FRR < 0.1% |
• Face |
FAR < 0.01%, FRR < 0.1% |
CARD TECHNOLOGY |
• RFID: 64-bit, 125kHz, RF output power (EN300-330) |
Yes |
• MIFARE: MFIS50/S70, 13.56MHz |
Made to order |
• HID: HID 1325, 26-bit, 125kHz |
Made to order |
COMMUNICATIONS |
• Method |
TCP/IP, RS232, RS485, USB disk (Optional WiFi & 4G) |
• Baud rates |
9600, 19200, 38400, 57600, 115200 |
• Wiegand |
26-bit output |
OPERATING ENVIRONMENT |
• Temperature (°C) |
0 ~ 45 |
• Humidity (%) |
20 ~ 80 |
• Power input |
DC 12V 3A |
TIME ATTENDANCE |
• Siren |
Internal and external |
• Work codes |
Yes |
• Fast Transaction Checking |
Yes |
MULTIMEDIA |
• Display |
4.3” 65K color TFT Touch Screen Panel |
• Photo-ID |
Yes |
• Short messaging |
Yes |
• Day Light Saving Timer |
Yes |
• Internal Backup Battery |
Yes (DC 12V, 2000mAh) |
ACCESS CONTROL |
• EM lock driving output |
DC12V / Relay output |
• Alarm output |
NO/NC |
VOICE / DISPLAY LANGUAGE (TERMINAL) |
English (Standard), Arabic, Indonesian, Chinese Traditional / Simplified,
Cantonese, Vietnamese, Spanish, Portuguese (Portugal), Turkish, Persian.
Other languages are available upon request. |
