R2c | FingerTec

R2c
Alternative to Master Terminal

2 YEARS LIMITED WARRANTY

Cost-Effective Access Solution

Lower Cost Without Compromisation

Pair R2c with R2 to secure both entrances and exits with absolute comfort and value for money.

Essential Biometrics With Easy Deployment

Designed For Versitility & Flexibility

Verification

Fingerprint
Card


Fingerprint	Card

Communication

RS485

Master terminal

Compact Design
Fit in Most Narrow Spaces and Door Frames

Comprehensive Card Options
Standardize One Option For All Card Access

RFID • MiFare

Access Control Management
Everything Under One Roof
All EM Lock driving outputs, alarm outputs, and anti-passback via the R2c can be diverted to be managed by a master terminal or Ingressus Controller in an access control system.

Anti-Passback
Tailgate, A Thing of The Past

Layout Plan

System Communication
for illustration only

Specification

MODEL	R2c
SURFACE FINISHING	Acrylonitrile butadiene styrene (ABS)
TYPE OF SCANNER	Non coated optical scanner
PROCESSOR	Managed by master
MEMORY	Managed by master
ALGORITHM	Supports BioBridge VX 10.0
PRODUCT DIMENSION (L X W X H), mm	64 x 42 x 135
STORAGE
• Fingerprint templates	Storge in master terminal
• Transaction logs	Storge in master terminal
ENROLLMENT & VERIFICATION
• Methods	Fingerprint (1:N) & card
• Recommended fingerprint per user ID	Managed by master
• Fingerprint placement	Any angle
• Verification time (sec)	Managed by master
• FAR (%)
• FRR (%)
CARD TECHNOLOGY
• RFID: 64-bit, 125kHz	Yes
• MIFARE: MFIS50/S70, 13.56MHz	Made to order
COMMUNICATIONS
• Method	RS485 (Connects to Master Terminal)
OPERATING ENVIRONMENT
• Temperature (°C)	0 ~ 45
• Humidity (%)	20 ~ 80
• Power input	Managed by master
ACCESS CONTROL
• EM lock driving output	Managed by master
• Alarm output
• Antipassback
